Re-Usable thermal electrical accessories for SUB, SUF and SUM
All electrical based parts supplied with the appropriate connector. Check out here more details cercell.com/products/accessory-products/thermal-control
Find part numbers and prices here:
|
|
Product description |
Part No. |
unit price EURO / € |
|
|
Silicone Electrical-Heating-Blanket (EHB) for SUB/SUF size OD 110 mm. Blanket rated at 110 VAC delivering 75 watt. Dimension 75x300 mm with 1.5 meter connection cabling. Supplied with IEC C14 male plug and clamping springs. May need an adapter. |
42920 |
500 |
|
|
Silicone Electrical-Heating-Blanket (EHB) for SUB/SUF size OD 110 mm. Blanket rated at 230 VAC delivering 75 watt. Dimension 75x300 mm with 1.5 meter connection cabling. Supplied with IEC C14 male plug and clamping springs. May need an adapter. |
42922 |
500 |
|
Silicone Electrical-Heating-Blanket (EHB) for SUB/SUF size OD 130 and OD 137 and OD 150 mm. Blanket rated at 110 VAC delivering 110 watt. Dimension 150x350 mm with 1.5 meter connection cabling. Supplied with IEC C14 male plug and clamping springs. May need an adapter. App 3 watt/cm2. |
42930 |
500 |
|
|
|
Silicone Electrical-Heating-Blanket (EHB) for SUB/SUF size OD 137 and OD 150 mm. Blanket rated at 230 VAC delivering 110 watt. Dimension 150x350 mm with 1.5 meter connection cabling. Supplied with male IEC C14 male plug and clamping springs. May need an adapter. App 3 watt/cm2. |
42932 |
500 |
|
Silicone Electrical-Heating-Blanket /EHB) for SUB/SUF size OD 137 and OD 150 mm. Blanket rated at 110 VAC delivering 75 watt. Dimension 75x350 mm with 1.5 meter connection cabling. Supplied with IEC C14 male connector and clamping springs. May need an adapter. App 5 watt/cm2. |
42940 |
500 |
|
|
Silicone Electrical-Heating-Blanket (EHB) for SUB/SUF size OD 137 and OD 150 mm. Blanket rated at 230 VAC delivering 75 watt. Dimension 75x350 mm with 1.5 meter connection cabling. Supplied with IEC C14 male plug and clamping springs. May need an adapter. App 5 watt/cm2. |
42942 |
500 |
|
|
Silicone Electrical-Heating-Blanket (EHB) for SUB/SUF size OD 200 and OD 250 mm. Blanket rated at 110 VAC delivering 200 watt. Dimension 200x450 mm with 1.5 meter connection cabling. Supplied with IEC C14 male connector and clamping springs. May need an adapter. App 3 watt/cm2. |
42950 |
750 |
|
|
|
Silicone Electrical-Heating-Blanket (EHB) for SUB/SUF size OD 200 and OD 250 mm. Blanket rated at 230 VAC delivering 200 watt. Dimension 200x450 mm with 1.5 meter connection cabling. Supplied with male IEC C14 male plug and clamping springs. May need an adapter. App 3 watt/cm2. |
42952 |
750 |
|
Heating-Support-Foot (HSF) for OD110 or OD137 mm SUBs or SUMs. Includes 150 watt integrated electrical cartridge heating elements. Rotary switch for 110 VAC or 230 VAC supply. Mounted with IEC C14 Panel Mount male socket. May need a cable adapter for your PCS. Square shaped aluminum construction with ID110 or ID137 mm to be bolted onto MST-Standard or MST-Compact. Choose your size XXX. |
42966-xxx |
3,850 |
|
|
Cable adapter's with IEC C13 female outlet socket. Inlet depends on your PCS - inform us and look at Cable Adapter's |
42512 |
500 |
|
| Cable adapter's with IEC C13 female outlet socket for Sartorius Biostate B-DCU
|
42514 |
500 |
|
|
|
Sterile-Filter-Heater / off-gas filter heater envelope, 3 Watt, for OD50 mm / 16 cm2 filter. Will run from 110 to 230 VAC. Supplied with EU, US, UK plugs. |
42911 |
400 |
|
|
Sterile-Filter-Heater / off-gas filter heater envelope, 8 Watt, for OD65 mm / 26 cm2 filter. Will operate from 110 to 230 VAC. Supplied with EU, US, UK plugs. |
42912 |
500 |
|
|
Sterile-Filter-Heater / off-gas filter heater blanket, 12.5 Watt, for 400 cm2 filter. Will operate from 110 to 230 VAC. Supplied with EU, US, UK plugs. |
42913 |
750 |
Accessories for thermal control of 500 ml SUB, SUF and SUM
SUB's, SUF's and SUM's delivered / designed with Magnetic-Bottom-Drive (MBD) to be driven by any of the MST or MSM. We suggest using the SUB-Support-Square bolted onto the MST and MSM. Check out cercell.com/support/thermal-system-details/small-cellvessel-heating
|
|
Product description |
Part No. |
unit price EURO / € |
|
Heating-Support-Foot (HSF) for 500 ml CellVessel / BactoVessel (OD 82 mm). No electrical heating or water cooling included. Aluminum construction with ID 82 for vessel and OD 137 x 40 mm supporting heating blanket (dim 38 x 349 mm). |
42897 |
500 |
|
|
|
Heating-Support-Foot (HSF-E) for 500 ml CellVessel / BactoVessel (OD 82 mm). Including 75 watt integrated electrical cartridge heating element. Choose between 110 VAC or 230 VAC (both with IEC C14 connector). Aluminum construction with OD 137 mm to fit into the ID137 mm SUB-Support-Square. Weight 1,300 grams. |
42897-E-xxx |
2,400 |
